Product feature:
1) High pressure, Max pressure:1.6MPa,
Outlet pressure: 1.2 MPa
2) body material: use zinc alloy replace aluminum alloy, high density, to avoid leakage
3) Excellent design, it can fill oil into Lubricator as automatic system keep working , no need to suspend
Specification
Model | Components | Port size Rc(G) | filter accuracy | Max. Flow L/min(ANR) | Working pressure Range MPa | Options/Description | |
Filter-Regulator | Lubricator | ||||||
FRC-MINI | LFR-MINI | LOE-MINI | 1/8″ | 40μm | 700 | 0.15~1.2 | -Manual drain type (Standard type) Can select Auto drain typeEnvironment current temperature: 5~60°C Recommended oil: Turbine oil No. ISOVG32Optional filter accuracy 5μm |
1/4″ | 1000 | ||||||
3/8″ | 1200 | ||||||
FRC-MIDI | LFR-MIDI | LOE-MIDI | 1/4″ | 1500 | |||
3/8″ | 2000 | ||||||
1/2″ | 2600 | ||||||
